Description
- Standard Programs Over 15 application programs included
- Sensitivity Up to 200 distinct sensitivity levels
- Zone Indications 20 zones
- Overhead Control Unit All electronics—LED, alarm light, bar
graph, control touch pads—integrated to
eliminate exposed wires, tampering. - Tamper-Proof Settings Three levels of access control
Self Diagnostic Program Complete and automatic
Zone Sensitivity Boost 20 Independently adjustable boosts. - Battery Packs (optional) 1.5 amp-hour and 14 amp-hour lithium
battery modules provide typical 1 hour or
10 hour operation times—integrated to
eliminate exposed wires, tampering. - Passageway Interior Size Width 30″ (0.76 m)
Height 80″ (2.03 m)
Depth 23″ (0.58 m) - Overall Exterior Size Width 35″ (0.90 m)
Height 87″ (2.21 m)
Depth 23″ (0.58 m) - Shipping Size Width 35.5″ (0.90 m)
Height 91.5″ (2.32 m)
Depth 6.25″ (.16 m) - Temperatures Operating: -4º F (-20º C) to +140º F (60º C)
Humidity to 95% non-condensing
Storage: -40º F (-40º C) to 158º F (70º C) - Power Fully automatic 100 to 240 VAC, 50 or 60 Hertz, 40 watts;
no rewiring, switching or adjustments needed - Regulatory Information Meets Electrical Safety and Compatibility Requirements
for CE, FCC, CSA, IEC, ICNIRP, IEEE. Additional certifications
pending. - Weatherproofing Meets IP 55, IEC 529 Standard for moisture, foreign
matter protection - Construction Attractive scratch and mar-resistant laminate. Detection
Head and Support: heavy duty aluminum. - Control Outputs (optional) Module connector via RS 485 cable provides NO/NC
relay contact using Relay Module - Remote Control (optional) Desktop Remote Control with Zone Indication and/or via
network with IoT Control Module (iC Module). - Networking (optional) Manage individual or groups of walkthroughs and
perform statistical analysis of throughput using iC
Module. - Random Alarm Feature Adjustable from 0 to 100 percent.
